SUN-CWDM T1310 Coarse Wavelength Division Multiplexer, 250um Bare Fiber without Connector

#310101
0 Sold 0 Reviews 0 Questions
PN: SUN-CWDM-T1310-25-05-OO-4225
Ship From China
263 in stock
Inquire Now
CWDM-T1310 Coarse Wavelength Division Multiplexer Device
SUN-CWDM T1310 Coarse Wavelength Division Multiplexer, 250um Bare Fiber without Connector #310101
0 Sold 0 Reviews 0 Questions
Inquire Now

 Features

  • Low insertion loss
  • Low PDL
  • High channel isolation
  • Excellent environmental reliability

Applications

  • WDM system
  • CATV

Wavelength 1260 ~ 1620 nm Insertion Loss Transmission: ≤0.6 dB; Reflection: ≤0.4 dB
Return Loss ≥ 45 dB Max. Optical Power ≤ 500 mW
PDL ≤ 0.1 dB Relative Humidity 5%~ 95%
Dimension Φ4.2×25 mm Operating Temperature -10℃ to +70℃
Storage Temperature -40℃ to +85℃
Quality Certifications
Quality Testing

Spectrum Testing

C-band Wavelength Testing

O-band Wavelength Testing

Parameter Testing

Production Workshop

Download

cwdm-device-data-sheet-310101.pdf
